It is used for various bicycle,motorcycle tube curing,except man operated tube operating and removal,the entitle curing process is automatically controlled. Its electrical parts adopt two ways of manual and linkage,equipped with PLC control system,thus ensuring simple,and reliable operation.
| 型號(hào)Type | LLN-800 Single-layer |
| 總壓力 Total pressure (KN) | 120 |
| 柱塞直徑 Dia. of plunger (mm) | 140 |
| 高壓壓力 High pressure (Mpa) | 10 |
| 低壓壓力 Low pressure (Mpa) | 1.8 |
| 蒸汽工作壓力 Steam working pressure (Mpa) | 0.7-1.0 |
| 電機(jī)功率 Motor power (kw) | 3 |
| 電氣控制 Electric control system | PLC |
| 外形尺寸 Overall dim. (LxWxH) (mm) | 6500x1100x1800 |
